Small Environmental Test Chambers
Lowest Temperature:-20℃/-40℃/-60℃/-86℃;
Temperature Range:-40℃～+150 ℃;
Humidity Range:10% ~ 98% RH;
Safety options for testing lithium-ion batteries
Built-in lighting for observing the test
Water Purification and Recirculation System
The LIB Industry Small Environmental Test Chamber provides precise temperature and humidity control in a compact desktop design. With a footprint of just 50L 80L, it delivers uniformity and stability for simulated environmental testing.
The Small Temperature Humidity Test Chamber provides a temperature range from -70°C to +150°C along with humidity control between 20% to 98% RH. An advanced PID control system drives the refrigeration, humidification, and heating systems.Whether you're testing electronic components, automotive parts, or conducting quality assurance research, our small environmental test chamber provides the precision and reliability you need. Built with advanced technology and backed by over 16 years of manufacturing expertise, these chambers offer laboratory-quality performance without requiring a dedicated testing facility.
Why Choose Our Compact Environmental Testing Solutions?
Space-Saving Desktop Design
Our chamber fits consistently on your standard research facility seat, taking up no more space than a huge printer. The compact impression makes it idealize for inquire about offices where each square foot things. You can position it right following to your other fundamental gear without disturbing your workflow.
Whisper-Quiet Operation
Operating at less than 65 dB, our chambers won't aggravate your concentration amid long testing sessions. The progressed quiet compressor plan guarantees you can work comfortably in the same room without clamor diversions. This makes our temperature mugginess chambers perfect for active inquire about situations and shared research facility spaces.
Plug-and-Play Convenience
No extraordinary electrical establishment required. Essentially plug into your standard office control outlet (220V/110V) and begin testing quickly. This disposes of exorbitant electrical updates and makes migration basic at whatever point your testing needs alter.
Technical Specifications
Model | TH-50 | TH-80 |
Internal Dimension (mm) | 320*350*450 | 400*400*500 |
Overall Dimension (mm) | 820*1160*950 | 900*1210*1000 |
Interior Volume | 50L | 80L |
Heat load | 1000W | |
Temperature Range | A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃ | |
Temperature Fluctuation | ± 0.5 ℃ | |
Temperature Deviation | ± 2.0 ℃ | |
Humidity Range | 20% ~ 98% RH | |
Humidity Deviation | ± 2.5% RH | |
Cooling Rate | 1 ℃ / min | |
Heating Rate | 3 ℃ / min | |
Cooling system | Mechanical compression refrigeration system | |
Controller | Programmable color LCD touch screen controller Ethernet connection | |
Safety Device | Humidifier Dry-combustion protection; Over-temperature Protection; Over-current Protection; Refrigerant High-pressure protection; Water Shortage Protection; Earth leakage Protection | |
Exterior Material | Steel Plate with protective coating | |
Interior Material | SUS304 stainless steel | |
Thermal Insulation | Polyurethane foam and insulation cotton | |
Observation Window | Interior lighting, double-layer thermo stability silicone rubber sealing | |
Standard Configuration | 1 Cable hole (Φ 50,) with plug; 2 shelves | |
Product Details
|
|
|
| Sample shelf SUS304 stainless steel punching sample shelf 2pcs; The height of the shelf is adjustable and can be removed | Controller PID programmable color touch screen controller network connection computer. Can create120 programs 100 segment. | Viewing Window Double layer insulating glass 8cm thick, made of tempered glass. built-in LED light for the work room lighting |
|
|
Advanced Features for Precise Testing
Superior Temperature & Humidity Control
Our environmental testing equipment uses high-precision PT100 Class A sensors with 0.001°C resolution. The advanced PID control system maintains exceptional stability throughout your testing cycles. Whether you need arctic cold storage conditions or tropical heat simulation, our system delivers consistent results.
Rapid Temperature Cycling
Save valuable testing time with our fast temperature change rates. The efficient cooling and heating systems reduce cycle times significantly, allowing you to complete more tests each day. Your productivity increases while maintaining the same high-quality results.
Smart Specimen Protection
The specially designed micro-circulation airflow system ensures even temperature distribution throughout the small testing space. Anti-condensation technology protects your valuable samples from moisture damage. The 50mm cable port allows for small environmental test chamber integrity.
User-Friendly Interface
The full-color touchscreen controller works as naturally as your smartphone. Program hundreds of test steps with ease, screen real-time conditions, and get to authentic information immediately. The huge perception window with warming anti-fog include lets you outwardly screen your tests all through the testing process.
Why Choose LIB Industry?
Proven Quality Standards
Our chambers take after strict ISO 9001 Quality Administration Framework conventions. Each unit gets CE certification and third-party testing by SGS and TUV specialists. This guarantees universal compliance and solid execution you can trust.
Comprehensive Guarantee Protection
Every natural chamber incorporates our industry-leading 3-year guarantee also lifetime benefit back. Our 24/7 worldwide back group gives help at whatever point you require it. If we can't repair your unit amid the guarantee period, we'll supplant it with a brand-new chamber at no cost.
Custom Solutions Available
Need particular adjustments for your interesting testing necessities? Our experienced designing group specializes in custom plans and non-standard applications. We work with you to make the idealize arrangement for your particular industry needs.
Start Testing Today
Ready to enhance your testing capabilities with a professional small environmental test chamber? Contact us at ellen@lib-industry.comfor detailed specifications, pricing, or to discuss your custom requirements.
