salt mist test machine
Temperature Range:+10 ℃ ～ +90 ℃
Humidity Range:30% ~ 98% RH
Salt Fog Deposition:1～2ml / 80cm2 · h
Cooling system Mechanical compression refrigeration system
Refrigerant:R404A(replaceable)
Air Preheating:Saturated air barrel (31Liter)
Salt Mist Test Machine - Professional Corrosion Testing Equipment
LIB industry progressed salt fog test machine conveys exact, standardized testing that makes a difference producers assess fabric solidness and coating adequacy. This advanced gear makes controlled salt haze situations to quicken erosion testing, giving exact comes about for quality confirmation over different businesses. Whether you require ASTM B117, ISO 9227, or other standard compliance, our testing chambers offer the unwavering quality and accuracy your research facility demands.
What Is a Salt Mist Test Machine?
A salt mist test machine is specialized research facility hardware planned to assess erosion resistance of materials and coatings. The machine makes an counterfeit salt haze environment utilizing atomized sodium chloride arrangement, quickening the characteristic erosion handle to give fast, dependable results.
These chambers recreate unforgiving natural conditions that materials confront in real-world applications. By uncovering test tests to controlled salt splash conditions, you can anticipate how your items will perform over amplified periods in destructive environments.
Technical Specifications of Salt Mist Test Machine
Model | S-150 | S-250 | S-750 | S-010 | S-016 | S-020 |
Internal dimensions (mm) | 590*470*400 | 1000*640*500 | 1100*750*500 | 1000*1300*600 | 900*1600*720 | 1000*2000*800 |
Overall dimensions (mm) | 1460*760*1140 | 1850*960*1350 | 1950*1030*1350 | 2000×1300×1600 | 2300×1300×1700 | 2700×1300×1900 |
Interior Volume (L) | 110 | 320 | 410 | 780 | 1030 | 1600 |
Temperature Range | Ambient ～ +60 ℃ | |||||
Temperature Fluctuation | ± 0.5 ℃ | |||||
Temperature Deviation | ± 2.0 ℃ | |||||
Humidity Range | 95% ~ 98% RH | |||||
Salt Fog Deposition | 1～2ml / 80cm2 · h | |||||
Spray Type | Continuous / Periodic | |||||
Salt Fog Collected | Fog collector and fog measure cylinder | |||||
Air Preheating | Saturated air barrel | |||||
Spraying System | Atomizer tower and Spray nozzles | |||||
Controller | PID controller | |||||
Safety Device | Humidifier Dry-combustion Protection; Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection | |||||
Material | Glass fiber reinforced plastics | |||||
Standard Configuration | 6 round bars and 5 V-shaped grooves | |||||
Standards Compliance | ASTM B117, ISO 9227, JIS Z2371, ASTM G85 | |||||
Sealing Structure | Water seal design | |||||
Product Details of Salt Mist Test Machine
|
|
|
| Controller Network connection computer. Language can be selected, English/French/Spanish/German/Russian | Salt Spray Device Spray tower is adjustable in height and spray volume to meet different test standards Salt spray nozzles are easy to clean | Salt Water Tank Built-in salt solution tank and external salt water tank Brine mixing system to keep the salt solution even |
|
|
Why Choose LIB Industry Salt Mist Test Machine?
Advanced Anti-Clogging Design
Our quartz spout innovation anticipates salt crystallization buildup that commonly pieces standard splash frameworks. This non-crystallization plan guarantees reliable fog conveyance all through expanded testing periods, decreasing support downtime and moving forward test reliability.
Superior Material Construction
The chamber development employments high-grade GFRP materials that stand up to solid acids, soluble bases, and tall temperatures. Our water seal structure avoids salt mist spillage, securing your research facility environment and other hardware from destructive damage.
Multi-Standard Compatibility
You can conduct different test sorts counting unbiased salt spray (NSS), acidic corrosive salt shower (AASS), and copper-accelerated acidic corrosive salt splash (CASS). The framework effectively switches between nonstop and cyclic testing modes to meet diverse standard requirements.
Automated Operation
The programmed salt water blending and filling framework dispenses with manual intercession amid long-duration tests. Built-in settlement volume observing permits you to track splash conveyance without opening the chamber, keeping up test integrity.
Professional Quality Assurance
All our hardware takes after ISO 9001 Quality Management System standards. Each unit gets CE certification and third-party testing by SGS and TUV, guaranteeing worldwide compliance and dependable performance.
Operating Standards & Compliance
Our equipment supports multiple international testing standards:
· ASTM B117: Standard practice for operating salt spray apparatus
· ISO 9227: Corrosion tests in artificial atmospheres
· JIS Z2371: Japanese standard for salt spray testing
· ASTM G85: Modified salt spray testing procedures
Each standard specifies different testing conditions, durations, and evaluation criteria. Our system accommodates these variations through programmable controls and flexible sample positioning.
Complete Testing Solution
Included Accessories
Every salt mist test machine comes with essential accessories including V-shaped sample holders, O-shaped support bars, collection funnels, and initial salt supplies. This complete package ensures immediate testing capability upon installation.
Professional Support
We provide comprehensive installation, training, and ongoing technical support. Our global service network includes locations in Malaysia, Canada, the United Kingdom, and the United States, ensuring prompt assistance worldwide.
Extended Warranty
All equipment includes a 3-year warranty with lifetime service support. If repair isn't possible within the warranty period, we provide complete replacement units to minimize laboratory downtime.
Getting Started
Ready to enhance your material testing capabilities? Contact our specialists at ellen@lib-industry.com to discuss your specific requirements and receive detailed technical specifications for our salt mist test machine solutions.
