temperature and humidity cabinet
Model: TH-225
Temperature Range:-86℃～+150 ℃;
Humidity Range:20% ~ 98% RH;
Safety options for testing lithium-ion batteries
Built-in lighting for observing the test
Water purification and recirculation system
Temperature and Humidity Cabinet: Precision Environmental Testing Solutions
Our temperature and humidity cabinet is designed to provide precise and stable environmental simulation for product reliability, durability, and performance testing. The chamber can typically achieve temperature ranges from -20°C, -40°C, or -70°C up to +150°C, with humidity control from 10% RH to 98% RH, enabling accurate and repeatable testing under a wide variety of climatic conditions.
The system is widely used to evaluate the effects of temperature and humidity on electronics, automotive components, aerospace products, pharmaceuticals, materials, and industrial equipment. By reproducing real-world environmental stresses in a controlled laboratory environment, it helps manufacturers verify product quality, improve reliability, and accelerate product development.
With customizable chamber volumes, temperature change rates, and optional configurations, LIB industry temperature and humidity cabinets can be tailored to meet specific testing requirements and international testing standards.
Key Features That Set LIB Industry Chambers Apart
Advanced Humidification System
Our outside humidification plan disposes of common issues like scaling and water spillage interior your test chamber. The humidifier works exterior the workspace, anticipating defilement and permitting support without ceasing your tests. The programmed water supply framework with built-in filtration guarantees ceaseless operation without manual intercession each few days.
Precise Temperature and Stickiness Control
You'll accomplish extraordinary exactness with temperature variances of as it were ±0.5°C and greatest deviation beneath ±2.0°C. Stickiness control keeps up solidness between 20%–98% RH with ±2.5% RH accuracy. Our high-precision PT100 Course A sensors give ±0.001°C determination, ensuring reliable and solid test results.
Energy-Efficient Refrigeration Technology
The electronic development valve (EEV) framework accurately controls refrigerant stream, conveying prevalent temperature control whereas diminishing vitality utilization by 20-30% compared to conventional heating-based frameworks. Premium compressor components from eminent brands guarantee solid, continuous operation.
Technical Specifications:
Model | TH-100 | TH-225 | TH-500 | TH-800 | TH-1000 |
Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 800*1000*1000 | 1000*1000*1000 |
Overall Dimension (mm) | 900*1050*1620 | 1000*1140*1870 | 1200*1340*2020 | 1300*1540*2120 | 1500*1540*2140 |
Interior Volume | 100L | 225L | 500L | 800L | 1000L |
Heat load | 1000W | ||||
Temperature Range | A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃ | ||||
Temperature Fluctuation | ± 0.5 ℃ | ||||
Temperature Deviation | ± 2.0 ℃ | ||||
Humidity Range | 20% ~ 98% RH | ||||
Humidity Deviation | ± 2.5% RH | ||||
Cooling Rate | 1 ℃ / min | ||||
Heating Rate | 3 ℃ / min | ||||
Cooling system | Mechanical compression refrigeration system | ||||
Refrigerating unit | French TECUMSEH compressor | ||||
Heating Element | Nichrome heater | ||||
Controller | Programmable color LCD touch screen controller, Ethernet connection | ||||
Water supply system | Automatic water supply, Water purification system | ||||
Humidifier | External isolation, stainless steel surface evaporation humidifier | ||||
Safety Device | Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection; Earth leakage protection | ||||
Exterior Material | Steel Plate with protective coating | ||||
Interior Material | SUS304 stainless steel | ||||
Thermal Insulation | Polyurethane foam and insulation cotton | ||||
Observation Window | Interior lighting, double-layer thermo stability silicone rubber sealing | ||||
Standard Configuration | 1 Cable hole with plug; 2 shelves | ||||
Product Details:
|
|
|
Automatic water inlet Automatic control of the water intake of equipment Water level alarm, water shortage lights and sound | Air circulation
The air is uniformly distributed through the air outlet Air circulates evenly throughout the workroom | Sample shelf
SUS304 stainless steel punching sample shelf 2pcs; Standard load of 50KGS for each layer of sample shelf |
|
|
Professional Quality You Can Trust
Since 2009, we've operated under ISO 9001 quality management standards. Every chamber receives CE certification and third-party verification from SGS and TUV, ensuring you receive equipment that meets international standards with stable, reliable performance.
Service That Supports Your Success
Your investment is protected with our 3-year warranty and lifetime service commitment. We provide 24/7 global support across our service centers in Malaysia, Canada, the United Kingdom, and the United States. If we can't repair your equipment within the warranty period, we'll replace it with brand-new equipment—no questions asked.
Custom Solutions for Unique Challenges
Standard specifications don't fit every application. Our engineering team specializes in non-standard designs and custom R&D. Tell us your specific requirements, and we'll develop a tailored solution that delivers optimal results for your industry and application.
Get Started Today
Ready to elevate your environmental testing capabilities? Our team is here to discuss your specific temperature and humidity cabinet requirements and recommend the right temperature humidity test chamber configuration for your needs.
